| SPECIFICATIONS | |
|---|---|
| Main Chipset | Hi3536C |
| Operating System | Embedded Linux |
| Bandwidth | 80M |
| Video Format | H.265 |
| Video Resolution | 5MP\3MP\2MP |
| Smart Functions | Target Count,Object Left/Lost, Electronic Fence, Line Crossing, Face Grouping List, Face Detection, Humanoid Detection, Retrograde Detection, Leave Position Detection (need front end IPC supported) |
| Record Mode | Manual, Schedule, Motion Detection, Timing, Alarm, Stop |
| Playback | 4CH 1080P, 1CH 5MP |
| Backup Mode | USB Device/Network |
| Video Input | 4CH Digital (2592X1944) + 4CH Preview + 4CH Playback + Face Recognition 2CH front end face capture 9CH Digital (2592X1944) + 9CH Preview + 9CH Playback + Face Recognition 4CH front end face capture 16CH Digital (2592X1944) + 16CH Preview + 9CH Playback + Face Recognition 4CH front end face capture 4CH Digital (3840X2160) + 4CH Preview + 4CH Playback 9CH Digital (3840X2160) + 9CH Preview + 9CH Playback 16CH Digital (3840X2160) + 16CH Preview + 16CH Playback 32CH Digital (2592X1944) + 32CH Preview + 9CH Playback |
| Video Output | 1 HDMI, 1 VGA |
| Audio Input & Output | HDMI audio |
| Alarm Input & Output | N/A |
| HDD | 2 SATA, MAX 8TB HDD |
| Network Interface | 1*RJ45 10M/100M self-adaptive LAN port |
| Network Function | DDNS,EMAIL,UPNP,NTP,DHCP,IP Filter,PPPoE,P2P |
| Smart Phone | iPhone, Android |
| USB | 2 USB Ports(2 USB2.0) |
| Power Supply | 12V 3A |
| Power Consumption | ≤10W(without HDD ) |
| Dimension | Equipment: 325X245X55mm, Packing: 370X85X340mm |
| Weight | N.W.: 1.2Kg; With Package: 1.3Kg |
