| SPECIFICATIONS | |
|---|---|
| Standard | Composite (baseband) video: NTSC, PAL, or SECAM |
| Impedance | Coaxial side: 75 ohms;UTP side: 100 ohms |
| Video Bandwidth | DC to 8 MHz |
| Maximum RF Input | 1.1 volts at 60 Hz |
| Insertion Loss | Less than 2 dB over the DC-to-8-MHz frequency range |
| Return Loss | Greater than 15 dB over the DC-to-8-MHz frequency range |
| Common-Mode Rejection | Greater than 40 dB at 8 MHz |
| Maximum Distance | With Category 3 cable: 1200 ft. (365.8 m) for color video, 1500 ft. (457.2 m) for black & white video; With Category 5 cable: 2200 ft. (670.6 m) for color video, 2500 ft. (762 m) for black & white video |
| RJ-45 Pins Used | 7 (Ring) and 8 (Tip), reverse-polarity-sensing |
| Connectors | IC440A: (1) RJ-45 female, (1) BNC male; IC444A: (2) screw terminals, (1) BNC male IC451A: (2) screw terminals, (1) mini BNC male on an 8" (20.3-cm) cable |
| Temperature Tolerance | Operating: 32 to 131˚F (0 to 55˚C); Storage: -4 to +185˚F (-20 to +85˚C) |
| Enclosure | Fire-retardant plastic |
| Size | IC440A: 1"H x 0.8"W x 1.8"D (2.5 x 2 x 4.6 cm); IC444A: 0.6"H x 0.6"W x 2.3"D (1.5 x 1.5 x 5.8 cm); IC451A: 1.3"H x 0.5"W x 0.5"D (3.3 x 1.3 x 1.3 cm) |
| Weight | 0.7 oz. (19.8 g) |
