| SPECIFICATIONS | |
|---|---|
| Smart Function | Humanoid detection |
| Main Chipset | Hi3516EV200 |
| Image Sensor | WDR (Off / Low / Medium / High) |
| 1/2.9″, 4MP progressive scan ultra-low illumination CMOS | Auto / Manual / Off |
| Effective Pixels | 4MP |
| Min. Illumination | Color: 0.1Lux@F1.2; B&W: 0Lux@F1.2(IR on) |
| Noise Reduction | 3D noise reduction |
| WDR | WDR (off / low / medium / high) |
| Image Setting | Brightness / contrast / sharpness / saturation / chroma |
| Video Bit Rate | Fixed bit rate, variable bit rate(1280kbps-4Mbps) |
| Audio Coding Standard | G.711U/64Kbps |
| Network Interface | 1*RJ45 10M/100M self-adaptive LAN port |
| Audio | Audio in, audio in & out for optional |
| Operation T/H | - 20°C ~ 55°C / 0﹪-90﹪ |
| Waterproof | IP66 |
| Power Supply | DC12V / POE optional |
| Mobile Monitoring | iPhone, Android |
| Power Consumption | <10W (MAX) |
