| Smart 5MP Varifocal Dome Network Camera | |
|---|---|
| Model | Hi3516EV3 |
| Image Sensor | 1/3″, 5MP progressive scan ultra-low illumination CMOS 2.7-13.5mm Motorized Zoom Lens |
| Day and Night Conversion Mode | ICR Switch, Automatic / Color / Black and White / External Trigger |
| WDR | DWDR (Off / Low / Medium / High) |
| Light Board Control | Auto / Manual / Off |
| 3D Noise Reduction | Off / Low / Medium / High / Higher |
| Mirror | Off / Horizontal Mirroring / Vertical Mirroring / 180 ° Rotation |
| Image Setting | Brightness / Contrast / Sharpness / Saturation / Chroma |
| Video Coding Standards | H.265/H.264 |
| Coding Characteristics | Main stream: 2592X1944 @20fps; Sub stream: 640X360 @20fps |
| Maximum Image Resolution | 2592X1944 |
| Video Bit Rate | Fixed bit rate, variable bit rate (192kbps-8000kbps) |
| Video Type | Composite stream / video stream |
| Audio Coding Standard | G.711U/64Kbps |
| Network Protocol | TCP/IP,UDP,HTTP,DHCP,RTSP,NTP |
| Interface Protocol | ONVIF |
| Network Interface | RJ45 10M/100M network adaptive |
| Audio | Line in / line out Optional |
| Power | DC12V / POE |
| Operating Temperature | -20°C ~ 55°C |
| Working Humidity | 0﹪-90﹪ |
