| SPECIFICATIONS | |
|---|---|
| Main Chipset | Hi3536 |
| Operating System | Embedded Linux |
| Bandwidth | 216M |
| Video Format | H.265 |
| Video Resolution | 4K\5MP\3MP\2MP |
| Smart Functions | Target Count,Object Left/Lost, Electric Fence, Line Crossing, Face Grouping List, Face Detection, Humaniod Detection, Retrograde Detection, Leave Position Detection (need front end IPC supported) |
| Record Mode | Manual, Schedule, Motion Detection, Timing, Alarm, Stop |
| Playback | 16CH 1080P, 4CH 4K |
| Backup Mode | USB Device/Network |
| Video Input | 36ch Digital (4000X3000) + 36ch Preview + 16ch Playback + Face Recognition 4ch front end face capture, 16ch front end comparision 16ch Digital (4000X3000) + 16ch Preview + 16ch Playback 25ch Digital (4000X3000) + 25ch Preview + 16ch Playback 36ch Digital (4000X3000) + 36ch Preview + 16ch Playback Support import 5000 face database |
| Video Output | 1 HDMI, 1 VGA |
| Audio Input & Output | 1 RCA in, 1 RCA out, HDMI audio |
| Alarm Input & Output | 4 in 1 out |
| HDD | 4 SATA, Each port supports MAX 8TB HDD |
| Network Interface | 2*RJ45 10M/100M/1000M self-adaptive LAN port |
| Network Function | DDNS,EMAIL,UPNP,NTP,DHCP,IP Filter,PPPoE,P2P |
| Smart Phone | iPhone, Android |
| USB | 3 USB Ports(2 USB2.0, 1USB3.0) |
| Power Supply | 12V 6.25A |
| Power Consumption | ≤25W(without HDD ) |
| Dimension | Equipment: 440mmx356mmx68.5mm Packing: 555mmX450mmX130mm |
| Weight | 5.7kg (without HDD) with package 6.9kg |
