5MP Smart Varifocal Bullet IP Network Camera

BNF-BH-5B-D2-P
1/2.9″, 5MP progressive scan ultra-low illumination CMOS
  • 1/2.9″, 5MP progressive scan ultra-low illumination CMOS 2.7-13.5mm motorized zoom lens
  • Color : 0.1Lux@F1.2; B&W: 0Lux@F1.2(IR on)
  • H.265, H.264
  • DWDR
  • BLC/3D DNR/ROI/HLC
SPECIFICATIONS
Image Sensor 1/3″, 5MP progressive scan ultra-low illumination CMOS
Day and Night Conversion Mode ICR Switch, Automatic / Color / Black and White / External Trigger
WDR WDR (Off / Low / Medium / High)
Light Board Control Auto / Manual / Off
3D Noise Reduction Off / Low / Medium / High / Higher
Mirror Off / Horizontal Mirroring / Vertical Mirroring / 180 ° Rotation
Image Setting Brightness / Contrast / Sharpness / Saturation / Chroma
Video Coding Standards H.265/H.264
Coding Characteristics Main stream: 2592X1944 @20fps; Sub stream: 640X360 @20fps
Maximum Image Resolution 2592X1944
Video Bit Rate Fixed bit rate, variable bit rate (192kbps-8000kbps)
Video Type Composite stream / video stream
Audio Coding Standard G.711U/64Kbps
Network Protocol TCP/IP,UDP,HTTP,DHCP,RTSP,NTP
Interface Protocol ONVIF
Network Interface RJ45 10M/100M network adaptive
Audio Line in / line out(Optional)
Power DC12V/POE
