| SPECIFICATIONS | |
|---|---|
| Smart Function | Target Count,Electronic Fence,Retrograde Detection, Leave Position smart function |
| Main Chipset | Hi3516V5 |
| Image Sensor | 1/2.9″, 3MP progressive scan ultra-low illumination CMOS |
| Effective Pixels | 3MP |
| Min. Illumination | Color: 0.1Lux@F1.2; B&W: 0Lux@F1.2(IR on) |
| Lens | 3.6/6mm |
| IR Distance | 20-30M (6 x IR III array IR lamps) |
| Noise Reduction | 3D noise reduction |
| WDR | WDR (off / low / medium / high) |
| Mirror | Off / horizontal mirroring / vertical mirroring / 180 ° rotation |
| Image Setting | Brightness / contrast / sharpness / saturation / chroma |
| Encoding Format | H.265/H.264 |
| Coding Characteristics | Main stream: 2304X1296 @20fps; Sub stream: 720X576 @25fps |
| Video Bit Rate | Fixed bit rate, variable bit rate(1280kbps-4Mbps) |
| Video Type | Composite stream / video stream |
| Audio Coding Standard | G.711U/64Kbps |
| Network Function | 1*RJ45 10M/100M self-adaptive LAN port |
| Network Protocol | TCP/IP, UDP, HTTP, DHCP, RTSP, NTP |
| Interface Protocol | ONVIF |
| Mobile Monitoring | iPhone, Android |
| Network Interface | RJ45 10M/100M network adaptive |
| POE | Builtin |
| Audio | Audio in & out Builtin |
| Operation T/H | - 20°C ~ 55°C / 0﹪-90﹪ |
| Waterproof | IP66 |
| Power Supply | DC12V /POE |
| Power Consumption | <10W (MAX) |
| Dimension (mm) | Equipment: 691.5(H)*Φ108(D)mm |
| Weight/PCS (g) | N.W.: 158g Packing: 210g |
